40x40ft Double Truss Container Canopy
> Overview
The 40x40ft Double Truss Container Canopy is a heavy-duty container shelter engineered as a TDS (Temporary Dismantlable Structure) for demanding industrial environments. Mounted directly onto shipping containers, it creates an immediate covered workspace or storage area without permanent foundations.
Designed to withstand harsh weather, this shipping container canopy combines a reinforced double truss steel frame with 900gsm fire-retardant PVC fabric, delivering superior wind and snow resistance compared to single truss systems. Ideal for construction compounds, aggregates yards, logistics hubs, and agricultural sites, it provides year-round protection for machinery, materials, vehicles, and workforce welfare zones.
Trusted by Tier 1 contractors, the 40ft container canopy is fully compliant with CE - certified EN 1090 fabrication, ensuring audit-ready documentation for blue-chip procurement. Backed by a 5-year warranty, it’s a relocatable, cost-efficient shelter solution built for long-term reliability.
> Key Benefits
- Enhanced Strength → Double truss frame for higher wind and snow tolerance than single-truss models.
- TDS Flexibility → Supplied as a Temporary Dismantlable Structure, enabling fast relocation with minimal groundworks.
- Compliance Ready → Designed in accordance with EN 1990 (Basis of Structural Design) and load requirements from EN 1991-1-3 (Snow) and EN 1991-1-4 (Wind).
- Durability Assured → Fabrication and welding to EN 1090-1/2 (CE/UKCA) with a 5-year structural warranty.
- Blue‑Chip Friendly → Documentation and specifications aligned with Tier 1 tender expectations.
> Technical Specifications
| Dimensions | 40ft x 40ft (12.2m x 12.2m) |
|---|---|
| Height (clearance) | 15ft (4.6m) |
| Frame | Double Truss Galvanised Steel, EN 1090 certified |
| Fabric | 900gsm fire-retardant PVC |
| Wind Tolerance | Up to 110 km/h (site-dependent; double truss reinforcement) |
| Snow Load | 0.6–0.7 kN/m² (Eurocode compliant) |
| Warranty | 5 years |
> Use Cases
> Construction & Civils (TDS Applications)
> Aggregates & Quarries
> Logistics & Warehousing
> Agriculture
> Tier 1 Infrastructure
> Installation & Delivery
- Nationwide delivery; international options available.
- Typical install in 2–3 working days by accredited teams (scissor lifts included).
- Designed as a Temporary Dismantlable Structure (TDS) — no permanent foundations required.
> Why Choose Varna Buildings?
Trusted by Tier 1 contractors, our double truss container canopies are engineered for compliance, durability, and rapid deployment — ideal where reliability and audit‑ready documentation matter.
> FAQs
> Is the double truss canopy certified to EN 1090?
> How does double truss differ from single truss?
> Is it relocatable as a TDS?
> What warranty is included?
